Start by locating the pin connector under the rear tailgate–identify the C2670 (gray, 16-pin) plug. Pin 13 carries the composite video signal (purple/white stripe), while pin 9 delivers ground (black/orange stripe). Power for the module originates from the fused ignition circuit (red/light blue, 10A fuse #37 in the BCM). If the display fails, probe these contacts with a multimeter: expect 12V on pin 5 (constant) and 8V on pin 11 (switched).
Route the harness along the existing OEM bundle–detach the driver-side rear quarter panel trim to avoid pinch points. The factory cable runs adjacent to the left taillight housing; secure splices with crimp connectors rated for 18AWG. For aftermarket units, match the NTSC standard (1V P-P, 75Ω impedance) to prevent signal degradation. Ground the shield directly to the chassis near the license plate frame to minimize interference.
Verify the RVC module (part HL3Z-19G490-A) by checking for CAN bus messages on pins 3 and 6 (yellow/green, high-speed bus). If the touchscreen ignores inputs, reflash the APIM using Ford’s IDS software v102.01 with the as-built data from module 7D0-01-01. For manual adjustments, short pin 15 to ground during ignition to force a factory reset–this clears stored DTCs like U0140 (lost communication with camera module).
Splice the reverse light trigger (white/pink stripe) before the bulb socket–this ensures the camera activates 200ms prior to gear engagement. Use a time-delay relay (Bosch 0 332 209 150) if the image lags; configure it for 0.5s hold time. For installations with trailer wiring adapters, isolate the camera feed with a diode (1N4007) to prevent backfeed into the tow module.
Avoid routing near the muffler or fuel filler neck–heat degrades the jacket. Test continuity with a tone generator (set to 1kHz) on the video line; if attenuation exceeds 3dB, replace the entire harness. For digital dash integrations, tap into the LIN bus (pin 16, gray/red stripe) only if the vehicle has SYNC 3.10+–earlier versions lack the required H.264 codec support.
Ford Truck Rear View System Electrical Layout Manual
Begin by locating the OEM harness connector near the tailgate assembly–pin 1 carries the video signal (yellow/black stripe), pin 2 is the ground (black), and pin 3 supplies 12V (red/purple stripe) when the transmission shifts to reverse. Disconnect the battery before splicing any wires to prevent short circuits.
- Use 18-gauge shielded coaxial cable for signal integrity; avoid solid-core alternatives prone to interference from tailgate torsion sensors.
- Connect the display unit’s power wire (purple/orange) to the reverse light circuit–tap into the auxiliary relay box behind the glove compartment, not directly to the bulb.
- Secure all splices with solder and adhesive-lined heat shrink; crimp connectors fail under vibration over time.
- Route cables away from exhaust manifolds and suspension components–minimum clearance: 2 inches.
If the screen flickers, check the ground connection first; ensure it terminates at the chassis rail, not the bed liner or trailer hitch. For aftermarket units, verify compatibility with Ford’s CAN bus protocol–resistance should read 60 ohms between signal and ground at idle voltage (0.5V).
Test the system with the engine running; voltage drops below 11.8V impair image stability. Keep a multimeter set to DC voltage within reach–measure at the tailgate connector if no feed appears on-screen.
Finding the Rear View Sensor Harness on Your Ford Truck
Start by removing the lower tailgate panel using a T20 Torx driver–clips are secured at the top edges and center. Once detached, trace the black 8-pin connector leading from the tail light assembly toward the truck bed; it’s bundled with the reverse light circuit harness and sits tucked behind the bumper support bracket.
Disconnect the negative battery terminal before handling any connectors to prevent short circuits. The harness splits near the rear differential–identify the 4-wire subset (red, black, yellow, and white) branching toward the license plate frame. Follow this subset upward through the pre-drilled grommet in the bed floor; push a coat hanger through from inside the cab to retrieve it if access is obstructed.
Verify the connection points by probing with a multimeter: red (12V when reverse is engaged), black (ground), yellow (video signal), white (shielded return). If readings are absent, inspect the inline fuse (10A) located behind the kick panel near the OBD-II port–corroded fuseboards are common after moisture exposure.
Reverse Image Sensor Connector Pinout Guide for Ford F-Series
Locate the OEM harness behind the tailgate on the driver’s side–pin 1 delivers +6V reference voltage identified by a solid green wire. Pin 2 (white with blue stripe) carries composite video signal; shield against EMI by pairing with chassis ground at pin 5. Confirm continuity between pin 3 (light green with red stripe) and the infotainment SYNC module connector C162B-6–this line triggers power-on when shifting to rear gear.
Critical Color Codes for Retrofit Integration
| Connector | Pin | Wire Color | Function | Voltage |
|---|---|---|---|---|
| C324 | 1 | Green | Supply (+) | 6V regulated |
| C324 | 2 | White/Blue | Video Out | 1Vpp NTSC |
| C324 | 3 | Light Green/Red | Gear Sense | 12V switched |
| C324 | 4 | Black/Orange | Illumination Dim | 10V PWM |
| C324 | 5 | Bare | Chassis Return | 0V |
Route video feed through a 75-ohm coaxial cable–avoid untwisting the conductors near the rear light assembly to prevent signal degradation. For aftermarket displays, tap into pin 2 using a BNC adapter; confirm impedance matching with a multimeter to 75 ohms ±5%. Integrate a 220µF electrolytic capacitor on pin 1 if screen flickers during cold starts–this stabilizes transient voltage drops.
Test switch activation by probing pin 3 with ignition on; expected voltage should rise from 0V to 12V when engaging reverse. If absent, verify continuity between C324-3 and the transmission range sensor wire (orange/light blue) at connector C104. Cross-splice errors often trace back to misrouted harnesses near the exhaust heat shield–secure ties every 15 cm to prevent chafing against the frame rail.
Integrating Third-Party Rear View Devices with OEM Electrical Systems
Locate the factory video input harness behind the infotainment display–typically a 6- or 8-pin connector marked “RGBS” or “CAM.” Use a multimeter to confirm pin assignments: the yellow wire carries composite video (1 Vp-p, 75Ω), the black wire serves as ground, and the red wire supplies 6V accessory power on 2011–2016 Ford platforms. Splice these directly to aftermarket harnesses using crimp connectors rated for 18 AWG wire; avoid soldering near dashboard plastics to prevent heat damage.
Critical Connection Points
- Reverse signal: Tap the pink/light blue wire at the transmission range sensor (TRS) or fuse box (fuse #29, 10A) to trigger automatic activation. Verify polarity with a test light–incorrect wiring will inhibit function.
- Parking guidelines: For dynamic grid overlays, route the purple/green wire from the aftermarket unit to the OEM parking aid module (RPO AP3). This requires CAN bus integration via an adapter like PAC RP5-FORD1.
- Power considerations: Aftermarket units exceeding 300mA draw necessitate a relay connected to the red accessory wire; failure causes intermittent image dropouts.
Secure all splices with heat-shrink tubing (minimum 4:1 shrink ratio) and route harnesses away from moving components (steering columns, HVAC actuators). Test functionality while shifting through all gears–Ford’s reverse lockout feature may interfere if the TRS signal isn’t properly mirrored.
Diagnosing Electrical Problems in the Ford Pickup Rear View System
Check the harness connection at the tailgate first–corrosion on the pins often disrupts signal flow. Detach the plug, clean contacts with 600-grit sandpaper, then apply dielectric grease to prevent oxidation. A multimeter set to 12V DC should read steady voltage between terminals A (power) and B (ground) when the ignition is on; fluctuations above 0.3V indicate a bad ground.
Pinpointing Intermittent Failures
Trace the coaxial cable from the sensor to the SYNC module beneath the dash–bends sharper than 5 cm radius can fracture the inner conductor. Replace the entire run if continuity drops below 75 ohms. Verify the reverse signal feed splices into the body control module’s pin C332-3; incorrect splicing triggers error code U2100 and disables the display without logging a DTC.
Inspect the inline fuse (10A) behind the glovebox–blown filaments from inductive loads in trailer wiring are common. Swap with a known-good fuse and monitor for 24 hours; recurrence points to a short upstream in the parking circuit or a malfunctioning trailer brake controller.
